OEM MEDICAL X-RAY FILM AX (blue sensitive) |
QUAM MEDICAL X-RAY FILM AX(blue sensitive) (made from Konica/Agfa master roll material) | TYPE | Description | Unit | (Boxes/Carton) | | | 8×10in×100NIF | box | 5 | | | 10×12in×100NIF | box | 5 | | Medical X-ray Film | 11×14in×100NIF | box | 5 | | Blue Sensitive AX (Q-AX) | 12×15in×100NIF | box | 5 | | | 14×14in×100NIF | box | 5 | | | 14×17in×100NIF | box | 5 |
| | | MEDICAL X-RAY FILM AX (model No.Q-AX is for exporting) has the characteristics of low fog. Powerful contrast, quick sensitivity and high resolution ratio. It can supply photos with high-clarity and high-penetration. It can be mainly used in the common x-ray photos for bones or chest.
 □ Clear Image Quality AX is developed by adopting the new-developed sensitive emulsion technology and decreases the scattering of the penetrating light at maximum limit. It can offer the photos with high-clarity, high-penetrating and powerful contrast.
AX has the characteristic of fog resistance. Therefore, it is uneasy to be infected by the scattered light and the fog drops greatly.
□ Outstanding Physical Characteristic Owing to the surface characteristic and its pressure resistance, AX can be operated efficiently in various kinds of automatic conveying equipment.
AX also has the functions of quick dry and new special static electricity protection of accumulation.
□ Stable Quality of the Finished Products AX is suitable for various kinds of operation methods, including the manual operation and the 90-second automatic operation.
AX has the characteristic which can prevent the contradictory between sensitivity and contrast and will offer the stable photos.
Notes for FUMINGWEI MEDICAL X-RAY FILM AX:
□ Usage:
Correctly handle the film. Avoid any damages by damp, sunlight, heating, rays or pressure.
□ Storage:
Store in a cool(temperature:10℃~20℃) and dry (air humidity: 30%~50% ) place. Keep it away from dampness, high temperature, any bad effective gases, x-ray, gamma ray or any other penetrating rays.
 □ Safelight:
Use a safelight filter (dark red) in a suitable safelight lamp equipped with a 15w ground bulb. Keep the film at a distance at least 1.2 meters from the safelight.
□ Automatic Developing:
All these three types can be developed by any kinds of film processor. It may get the better effect by using the film processor of KONICA, type SRX-201 and the kit of KONICA, XD-90.
□ Manual Developing:
Use the kit of KONICA, XD-90 for developing and fixing or the same kinds of kit by film processor at high temperature or by hand at the normal atmospheric temperature.
□ Usage of the Intensifying Screen:
QUAM MEDICAL X-RAY FILM AX can be matched with NH intensifying screen of KONICA or the screen of the other same system which matches the blue sensitive x-ray film. |
|
